Fully Automatic Servo Pull Down Broaching Machine
Fully Automatic Servo Pull Down Broaching Machine Manufacturer
- The machine tool has a pull-down structure
- Using imported linear guides, screw rods, and bearings from Germany, the stability is reliable and the efficiency is high.
- Low noise vibrating plate is used for feeding, and the product can be tested automatically.
|Pulling force (KN)||50||100||150|
|Max. stroke (mm)||800||1000||1200/1400|
|Cutting speed (m/min,60Hz)||1-8||1-8||1-8|
|Return speed (m/min, 60Hz)||15||15||15|
|Broach lifter stroke (mm)||600||600||600|
|Bolster hole diameter (mm)||100||120||150|
|Max. workpiece dia (mm)||200||200||200|
|Main motor (kw)||11||15||22|
|Machine height (mm)||4000||4500||5000|
|Floor space (mm x mm)||1500 x 3000||1500 x 4000||2500 x 4500|
Chengchun Broaching Machine Factory Offers Diverse Broaching Solutions
We have developed a series of high precision,high performance automatic broaching equipment-full digital AC servo broaching machine,full-automatic CNC broaching machine,full-automatic spiral broaching machine,hydraulic broaching machine and so on. The pulling force of our broaching machines range from 50KN to 1000KN.Our equipment features the characteristic of high precision,low noise,good stability,high production efficiency,easy installation and convenient operation.
