Helical internal spline broaching machine

Helical internal spline broaching machine Manufacturer

  • Even if the dimensions of the helical splines are different or the straight splines are processed, they can be switched freely
  • By combining with the optional high-speed device, it is possible to realize the flexible production of the automatic production line
  • Suitable for high-efficiency machining of internal helical gears for small reducers and clutches of two-wheelers
  • Compact design saves space

Processing examples

Processing examples
Helical internal spline broaching machine
Technology Parameter
Send Inquiry
Download Catalog
CCLC-LX-T5CCLC-LX-T10CCLC-LX-T20
Pulling force (KN)50100200
Max. stroke (mm)600/8001000/12001400/1600
Cutting speed (m/min,60Hz)0-100-10
Return speed (m/min, 60Hz)202015
Broach lifter stroke (mm)600600600
Bolster hole diameter (mm)100100200
Max Workpiece Dia(mm)120150300
Main motor (kw)7.2/1130Double 15X2
Machine height (mm)400045005500
Floor space (mm x mm)1800X30002000X40002000X5000
Weight (t)5812

Chengchun Broaching Machine Factory Offers Diverse Broaching Solutions

We have developed a series of high precision,high performance automatic broaching equipment-full digital AC servo broaching machine,full-automatic CNC broaching machine,full-automatic spiral broaching machine,hydraulic broaching machine and so on. The pulling force of our broaching machines range from 50KN to 1000KN.Our equipment features the characteristic of high precision,low noise,good stability,high production efficiency,easy installation and convenient operation.

broaching machine

Automatic broaching machine

Our broaching equipment can be designed according to user needs to develop a fully enclosed automatic loading and unloading broaching center, which consists of a loading system, a conveyor belt, an unloading system, and a broaching machine.
External Broaching Machine

Hydraulic Broaching Machine

Our hydraulic broaching machines are suitable for processing various types of internal gears, internal splines, and inner holes of geometric shapes.
Automatic Broaching Machine

Vertical Broaching Machine

Chengchun Automation Equipment Co., Ltd. produces and sells a series of high-precision vertical broaching machines such as vertical pull-up broaching machines, vertical pull-down broaching machines, and vertical surface broaching machines.
Helical Broaching Machine

Helical Broaching Machine

Our helical broaching machine is suitable for high-precision broaching of internal teeth of helical splines, driven by servo, which can quickly switch between broaching of helical splines and straight splines of different specifications.
Horizontal Broching Machine

Horizontal Broching Machine

Our horizontal broaching machines are suitable for high-precision broaching of holes or keyways.
automatic broaching machine

Hard Broaching Machine

Our hard broaching machine is mainly used for shaping and processing the inner hole, inner spline, and various internal teeth of the workpiece after heating.
Helical Broaching Machine

Internal Broaching Machine

Our broaching machines are mainly used in the processing of internal teeth, internal splines, and holes of auto parts, reducers, and other industrial products.
Surface Broaching Machine

Surface Broaching Machine

Chengchun Automation Equipment Co., Ltd. produces and sells a series of high-precision surface broaching production equipment such as horizontal broaching machines, and vertical surface broaching machines.
External Broaching Machine

External Broaching Machine

Our external broaching machine has a pulling force ranging from 50KN to 1000KN and It has the characteristics of high precision, low noise, good stability, high production efficiency, easy installation, and convenient operation.
