High Speed Pull-Up Hard Broaching Machine
High Speed Pull-Up Hard Broaching Machine Manufacturer
- The cutting speed of this series of broaching machines is 0~70 m/min, which is in line with the best processing conditions of 50~60 m/min for hard broaching.
- The broaching machine adopts linear roller guides and high-rigidity special ball screws to ensure the reliability of the equipment during high-speed driving.
- According to the rigidity analysis, optimize the design of the machine body and worktable.
- An adjustable worktable improves productivity by lowering the workpiece mounting height.
- No hydraulic system, saving energy and space.
|Pulling force (KN)||100|
|Max. stroke (mm)||1300|
|Cutting speed (m/min,60Hz)||0-70|
|Return speed (m/min, 60Hz)||0-70|
|Work Table Surface Hight(mm)||1100|
|Max Workpiece Dia(mm)||Customize|
|Main motor (kw)||100|
|Machine height (mm)||3700|
|Floor space (mm x mm)||2300X3400|
Chengchun Broaching Machine Factory Offers Diverse Broaching Solutions
We have developed a series of high precision,high performance automatic broaching equipment-full digital AC servo broaching machine,full-automatic CNC broaching machine,full-automatic spiral broaching machine,hydraulic broaching machine and so on. The pulling force of our broaching machines range from 50KN to 1000KN.Our equipment features the characteristic of high precision,low noise,good stability,high production efficiency,easy installation and convenient operation.
