Horizontal External Broaching Machine
Horizontal External Broaching Machine Manufacturer
This broaching machine is a special horizontal broaching machine for flange end teeth, which has the characteristics of high precision and high efficiency.
Processing examples
Processing examplesCCLC-C20-W | CCLC-C30-W | |
---|---|---|
Pulling force (KN) | 200 | 300 |
Max. stroke (mm) | 1800 | 2000 |
Cutting speed (m/min,60Hz) | 0-8 | 0-8 |
Return speed (m/min, 60Hz) | 0-15 | 0-15 |
Main motor (kw) | 22 | 30 |
Machine height (mm) | 2800 | 3500 |
Floor space (mm x mm) | 5100X3000 | 6050X4750 |
Weight/T | 0.9 | 1 |
Chengchun Broaching Machine Factory Offers Diverse Broaching Solutions
We have developed a series of high precision,high performance automatic broaching equipment-full digital AC servo broaching machine,full-automatic CNC broaching machine,full-automatic spiral broaching machine,hydraulic broaching machine and so on. The pulling force of our broaching machines range from 50KN to 1000KN.Our equipment features the characteristic of high precision,low noise,good stability,high production efficiency,easy installation and convenient operation.
