Hydraulic Vertical Pull-Down Broaching Machine
Hydraulic Vertical Pull-Down Broaching Machine Manufacturer
This series of lathes are vertical internal broaching machines with semi-protection and full escort structure. The auxiliary sliding plate is installed on the main sliding plate. When the broaching machine is working, the clamping device of the main and auxiliary sliding plate can effectively support the front and rear shanks of the broach at the same time, so as to ensure that the broach is fixed during the working process, and the two ends do not move. The workpiece to be processed is fixed on the worktable after being self-centering, the broach moves downward, and the broaching is completed to return and return. The full escort broaching method effectively guarantees the precision and stability of the machined parts. The installation methods of this equipment are divided into ground installation and buried installation.
|Pulling force (KN)
|Max. stroke (mm)
|Cutting speed (m/min,60Hz)
|Return speed (m/min, 60Hz)
|Max Workpiece Dia(mm)
|Main motor (kw)
|Machine height (mm)
|Floor space (mm x mm)
Chengchun Broaching Machine Factory Offers Diverse Broaching Solutions
We have developed a series of high precision,high performance automatic broaching equipment-full digital AC servo broaching machine,full-automatic CNC broaching machine,full-automatic spiral broaching machine,hydraulic broaching machine and so on. The pulling force of our broaching machines range from 50KN to 1000KN.Our equipment features the characteristic of high precision,low noise,good stability,high production efficiency,easy installation and convenient operation.
